MY26 Vala C MidnightGreen

Vala 1 MY26

Rahmen-Spezifikationen

Innenlager-Schale EMTB
Hintere Bremsaufnahme 200mm PM
Dämpfer-Einbauänge 205mm
Fork Axle to Crown 571mm
Gabel-Offset 44mm
Front Derailleur Mount No Compatibility
Steuersatz Integrated (IS41/52)
Maximale Kettenblattgröße 36t
Max. Bremsscheibengröße 220mm
Maximale Reifenfreiheit 2.5"
Einbaubreite hinten 148mm
Federweg hinten 151mm
Recommended Sag 30%
Sattelklemmung 36.4mm
Sattelstützen-Durchmesser 31.6mm
Dämpferhub 60mm
Federungssystem Four-bar
UDH kompatibel Yes
Flaschenhalteraufnahmen 1

Ausstattungsvarianten

Wähle eine Ausstattungsvariante

Frame Carbon C MX 150mm Travel, 4-Bar
Federweg 150mm
Material Carbon C
Laufradgröße MX
Gewicht 49.14lbs / 22.29kg
Akku Bosch PowerTube Battery 600Wh
Tretlager N/A
Bremsen SRAM DB8
Kassette SRAM XS 1270 Eagle T-Type, 10-52t
Kette SRAM 70 Eagle T-Type, Flattop, 12spd
Kettenführung OneUp Chainguide
Kurbelgarnitur E13 Helix eSpec, 160mm
Motor Bosch Performance CX BDU38
Gabel RockShox Zeb Base, 160mm
Nabe vorne SRAM MTH 716, 15x110, 6-Bolt, 32h
Felge vorne Reserve 30|HD AL
Bremsscheibe vorne SRAM Centerline, 220mm
Vorderreifen Maxxis Assegai 29"x2.5", 3C MaxxGrip, EXO+
Griffe Santa Cruz Bicycles House Grips
Lenker Burgtec Alloy Bar -or- e13 TRS Base Bar
Steuersatz Cane Creek 10 IS Integrated Headset
Schaltwerk SRAM 70 Eagle T-Type, 12spd
Nabe hinten SRAM MTH 746, 12x148, HG, 6-Bolt, 32h
Felge hinten Reserve 30|HD AL
Bremsscheibe hinten SRAM Centerline, 200mm
Dämpfer FOX Float X Performance, 205x60
Hinterreifen Maxxis Minion DHRII 27.5"x2.5", 3C MaxxTerra DoubleDown
Sattel SDG Bel-Air V3 Max
Sattelstütze SDG Tellis Dropper, 31.6
Vorbau OneUp Enduro Stem, 42mm -or- e13 TRS Base Stem, 40mm
Ventile Reserve Fillmore Valves
Frame Carbon C MX 150mm Travel, 4-Bar
Federweg 150mm
Material Carbon C
Laufradgröße MX
Gewicht 48.93lbs / 22.19kg
Akku Bosch PowerTube Battery 600Wh
Tretlager N/A
Bremsen SRAM Maven Base
Kassette SRAM XS 1275 Eagle T-Type, 10-52t
Kette SRAM GX Eagle T-Type, Flattop, 12spd
Kettenführung OneUp Chainguide
Kurbelgarnitur E13 Helix eSpec, 160mm
Motor Bosch Performance CX BDU38
Gabel FOX 38 Float Performance, Grip, 160mm
Nabe vorne E13 SL, 15x110, 6-Bolt, 32h
Felge vorne Reserve 30|HD AL
Bremsscheibe vorne SRAM HS2 200mm
Vorderreifen Maxxis Assegai 29"x2.5", 3C MaxxGrip, EXO+
Griffe Santa Cruz Bicycles House Grips
Lenker OneUp Aluminum Bar
Steuersatz Cane Creek 10 IS Integrated Headset
Schaltwerk SRAM 90 Eagle T-Type, 12spd
Nabe hinten E13 SL E-Spec, 12x148, XD, 6-Bolt, 32h
Felge hinten Reserve 30|HD AL
Bremsscheibe hinten SRAM HS2 200mm
Dämpfer FOX Float X Performance, 205x60
Hinterreifen Maxxis Minion DHRII 27.5"x2.5", 3C MaxxTerra DoubleDown
Sattel SDG Bel-Air V3, Max Lux-Alloy
Sattelstütze OneUp Dropper Post, 31.6
Vorbau OneUp Enduro Stem, 42mm
Ventile Reserve Fillmore Valves
Frame Aluminum MX 150mm Travel, 4-Bar
Federweg 150mm
Material Aluminum
Laufradgröße MX
Akku Bosch PowerTube Battery 600Wh
Tretlager N/A
Bremsen Shimano Deore M6120
Kassette Shimano Deore 6100, 10-51t
Kette Shimano Deore 6100, 12spd
Kettenführung OneUp Chainguide
Kurbelgarnitur E13 Helix eSpec, 160mm
Motor Bosch Performance CX BDU38
Gabel RockShox Psylo Gold RC, 160mm
Nabe vorne WTB Frequency Sport, 15x110, 6-Bolt, 32h
Felge vorne WTB ST Tough 30
Bremsscheibe vorne Shimano RT66, 220mm
Vorderreifen Maxxis Assegai 29"x2.5", EXO+
Griffe Santa Cruz Bicycles House Grips
Lenker Santa Cruz Bicycles Aluminum Bar, 35x800, 30mm Rise
Steuersatz FSA IS-2/47/42 ACB
Schaltwerk Shimano Deore M6100, SGS, 12spd
Nabe hinten WTB Frequency Sport, 12x148, MicroSpline, 6-Bolt, 32h
Felge hinten WTB ST Tough 30
Bremsscheibe hinten Shimano RT66, 203mm
Dämpfer RockShox Deluxe Select, 205x60
Hinterreifen Maxxis Minion DHRII, 27.5"x2.5", DoubleDown
Sattel WTB Silverado Medium, Steel
Sattelstütze SDG Tellis Dropper, 31.6
Vorbau OneUp Enduro Stem, 42mm
Ventile Reserve Fillmore Valves
Frame Aluminum MX 150mm Travel, 4-Bar
Federweg 150mm
Material Aluminum
Laufradgröße MX
Akku Bosch PowerTube Battery 600Wh
Tretlager N/A
Bremsen SRAM DB8
Kassette SRAM XS 1270 Eagle T-Type, 10-52t
Kette SRAM 70 Eagle T-Type, Flattop, 12spd
Kettenführung OneUp Chainguide
Kurbelgarnitur E13 Helix eSpec, 160mm
Motor Bosch Performance CX BDU38
Gabel RockShox Zeb Base, 160mm
Nabe vorne SRAM MTH 716, 15x110, 6-Bolt, 32h
Felge vorne Reserve 30|HD AL
Bremsscheibe vorne SRAM Centerline, 220mm
Vorderreifen Maxxis Assegai 29"x2.5", 3C MaxxGrip, EXO+
Griffe Santa Cruz Bicycles House Grips
Lenker Santa Cruz Bicycles Aluminum Bar, 35x800, 30mm Rise
Steuersatz FSA IS-2/47/42 ACB
Schaltwerk SRAM 70 Eagle T-Type, 12spd
Nabe hinten SRAM MTH 746, 12x148, HG, 6-Bolt, 32h
Felge hinten Reserve 30|HD AL
Bremsscheibe hinten SRAM Centerline, 200mm
Dämpfer RockShox Super Deluxe Base, 205x60
Hinterreifen Maxxis Minion DHRII, 27.5"x2.5", DoubleDown
Sattel WTB Silverado Medium, Steel
Sattelstütze SDG Tellis Dropper, 31.6
Vorbau OneUp Enduro Stem, 42mm
Ventile Reserve Fillmore Valves
Frame Carbon C MX 150mm Travel, 4-Bar
Federweg 150mm
Material Carbon C
Laufradgröße MX
Gewicht 48.46lbs / 21.98kg
Akku Bosch PowerTube Battery 600Wh
Tretlager N/A
Bremsen SRAM Maven Bronze
Kassette SRAM GX 1275 Eagle T-Type, 10-52t
Kette SRAM GX Eagle T-Type, Flattop, 12spd
Kettenführung OneUp Chainguide
Kurbelgarnitur SRAM GX Eagle Cranks, 160mm
Motor Bosch Performance CX BDU38
Gabel FOX 38 Float Performance Elite, Grip X2, 160mm
Nabe vorne E13 SL, 15x110, 6-Bolt, 32h
Felge vorne Reserve 30|HD AL 6069
Bremsscheibe vorne SRAM HS2 200mm
Vorderreifen Maxxis Assegai 29"x2.5", 3C MaxxGrip, EXO+
Griffe Santa Cruz Bicycles House Grips
Lenker OneUp Aluminum Bar, 35mm Rise, 800mm
Steuersatz Cane Creek 50 IS Integrated Headset
Schaltwerk SRAM GX Eagle AXS T-Type, 12spd
Nabe hinten E13 SL E-Spec, 12x148, XD, 6-Bolt, 32h
Felge hinten Reserve 30|HD AL 6069
Bremsscheibe hinten SRAM HS2 200mm
Dämpfer FOX Float X Performance Elite, 205x60
Hinterreifen Maxxis Minion DHRII 27.5"x2.5", 3C MaxxTerra, DoubleDown
Sattel SDG Bel-Air V3 Max Lux-Alloy Atmos
Sattelstütze OneUp Dropper Post, 31.6
Vorbau OneUp Enduro Stem, 42mm
Ventile Reserve Fillmore Valves
Frame Carbon CC MX 150mm Travel, 4-Bar
Federweg 150mm
Material Carbon CC
Laufradgröße MX
Gewicht 46.53lbs / 21.1kg
Akku Bosch PowerTube Battery 600Wh
Tretlager N/A
Bremsen SRAM Maven Silver
Kassette SRAM X0 1295 Eagle T-Type, 10-52t
Kette SRAM X0 Eagle T-Type, Flattop, 12spd
Kettenführung OneUp Chainguide
Kurbelgarnitur SRAM X0 Eagle Cranks, 160mm
Motor Bosch Performance CX BDU38
Gabel FOX 38 Factory, Grip X2, 160mm
Nabe vorne DT Swiss 350, 15x110, 6-Bolt, 28h
Felge vorne Reserve 30|HD Carbon
Bremsscheibe vorne SRAM HS2 200mm
Vorderreifen Maxxis Assegai 29"x2.5", 3C MaxxGrip, EXO+
Griffe Santa Cruz Bicycles House Grips
Lenker Santa Cruz Carbon Bar
Steuersatz Cane Creek 50 IS Integrated Headset
Schaltwerk SRAM X0 Eagle AXS T-Type, 12spd
Nabe hinten DT Swiss 350 DEG, 12x148, XD, 6-Bolt, 72t, 28h
Felge hinten Reserve 30|HD Carbon
Bremsscheibe hinten SRAM HS2 200mm
Dämpfer FOX Float X Factory, 205x60
Hinterreifen Maxxis Minion DHRII 27.5"x2.5", 3C MaxxTerra, DoubleDown
Sattel WTB Silverado Medium Fusion, CroMo SL
Sattelstütze OneUp Dropper Post, 31.6
Vorbau OneUp Enduro Stem, 42mm
Ventile Reserve Fillmore Valves
Frame Carbon CC MX 150mm Travel, 4-Bar
Federweg 150mm
Material Carbon CC
Laufradgröße MX
Gewicht 46.6lbs / 21.13kg
Akku Bosch PowerTube Battery 600Wh
Tretlager N/A
Bremsen SRAM Maven Ultimate
Kassette SRAM XX 1297 Eagle T-Type, 10-52t
Kette SRAM XX Eagle T-Type, Flattop, 12spd
Kettenführung OneUp Chainguide
Kurbelgarnitur SRAM X0 Eagle Cranks, 160mm
Motor Bosch Performance CX BDU38
Gabel FOX 38 Factory, Grip X2, 160mm
Nabe vorne Industry Nine Hydra 2, 15x110, 6-Bolt 28h
Felge vorne Reserve 30|HD Carbon
Bremsscheibe vorne SRAM HS2 200mm
Vorderreifen Maxxis Assegai 29"x2.5", 3C MaxxGrip, EXO+
Griffe Santa Cruz Bicycles House Grips
Lenker Santa Cruz Carbon Bar
Steuersatz Chris King DropSet 3 Integrated Headset
Schaltwerk SRAM XX Eagle AXS T-Type, 12spd
Nabe hinten Industry Nine Hydra 2, 12x148, XD, 6-Bolt 28h
Felge hinten Reserve 30|HD Carbon
Bremsscheibe hinten SRAM HS2 200mm
Dämpfer FOX Float X Factory, 205x60
Hinterreifen Maxxis Minion DHRII 27.5"x2.5", 3C MaxxTerra, DoubleDown
Sattel WTB Silverado Medium Fusion, Stainless
Sattelstütze RockShox Reverb AXS
Vorbau Burgtec Enduro MK3 Machined, 42mm
Ventile Reserve Fillmore Valves

Geometrie

Flip Chip
Alle Einheiten in Millimeter oder Grad
S M L XL XXL
Reach 435 460 480 500 525
Stack 623 632 641 655 668
Head tube angle 64.2° 64.2° 64.2° 64.2° 64.2°
Steuerrohrlänge 110 120 130 145 160
Hinterbaulänge 439 440 443 446 450
Front Center 771 800 825 851 883
Tretlagerhöhe 344 344 344 344 344
BB Drop Front 28 28 28 28 28
BB Drop Rear 11 11 11 11 11
Radstand 1210 1240 1268 1297 1333
Oberrohrlänge 573 601 622 645 673
Sitzrohrlänge 380 400 420 460 500
Sitzwinkel 77.5° 77.5° 77.5° 77.5° 77.5°
Überstandshöhe 741 735 734 734 728
S M L XL XXL
Reach 432 456 477 497 522
Stack 625 635 643 657 670
Head tube angle 63.9° 63.9° 63.9° 63.9° 63.9°
Steuerrohrlänge 110 120 130 145 160
Hinterbaulänge 439 440 443 446 450
Front Center 771 800 825 851 883
Tretlagerhöhe 340 340 340 340 340
BB Drop Front 32 32 32 32 32
BB Drop Rear 15 15 15 15 15
Radstand 1210 1240 1268 1297 1333
Oberrohrlänge 573 601 622 645 673
Sitzrohrlänge 380 400 420 460 500
Sitzwinkel 77.2° 77.2° 77.2° 77.2° 77.2°
Überstandshöhe 741 735 734 734 728
S M L XL
Reach 433 458 478 498
Stack 625 634 643 656
Head tube angle 64.1° 64.1° 64.1° 64.1°
Steuerrohrlänge 110 120 130 145
Hinterbaulänge 440 440 445 445
Front Center 771 800 825 851
Tretlagerhöhe 342 342 342 342
BB Drop Front 30 30 30 30
BB Drop Rear 13 13 13 13
Radstand 1211 1241 1270 1297
Oberrohrlänge 578 606 628 652
Sitzrohrlänge 380 400 420 460
Sitzwinkel 76.9° 76.9° 76.8° 76.8°
Überstandshöhe 744 745 729 732

Größen-Empfehlung

S
154cm 5'1" - 165cm 5'5" Reach: 435mm
M
165cm 5'5" - 175cm 5'9" Reach: 460mm
L
175cm 5'9" - 185cm 6'1" Reach: 480mm
XL
182cm 6'0" - 193cm 6'4" Reach: 500mm
XX-Large (Carbon Only)
193cm 6'4" - 200cm 6'7" Reach: 525mm

Schaltungs-Einstellung

Frame Size Flip Chip Setup Key Setup Cog 32T 34T 36T
S - Carbon High A 7 116 118 118
M - Carbon High B 7 118 118 120
L - Carbon High A 7 118 120 120
XL - Carbon High A 7 118 120 120
XXL - Carbon High A 7 118 120 120
S - Carbon Low A 7 116 118 118
M - Carbon Low A 7 116 118 118
L - Carbon Low A 7 118 120 120
XL - Carbon Low A 7 118 120 120
XXL - Carbon Low A 7 118 120 120
S - AL None B 7 118 118 120
M - AL None B 7 118 118 120
L - AL None B 7 118 118 120
XL - AL None B 7 118 118 120

Explosionszeichnungen

Carbon - Pivot Bearings
label part_number quantity name blurb
A 26-11612 4 Bearing Dust Shield Apply grease to inner surface
B 11-12218 4 6902-2RS Max Bearing
C 26-17707 1 15x48 Bearing spacer
D 26-17013 1 15x40.25 Bearing Spacer
Exploded Diagram of Vala
Carbon - Controller, Motor, Downtube Protector, and Shuttle Guard
label part_number quantity name blurb torque
A 20-27756 1 Head Tube Badge Clean frame surface, center on headtube
B 26-27915 4 M5x10 BHCS Apply Loctite 242 to threads 9 Nm
C 30-27825 1 Shuttle guard Line up with battery screws
D 72-25239 1 Bosch DU Performance CX Bosch part number EB11.100.00E
E 26-23102 3 M4x16 BHCS Apply grease to threads 0.65 Nm
F 30-27496 1 DU protector Use 30-27495 for size S & M
G 26-21224 2 M6x10 BHCS Apply loctite to threads 3 Nm
H 26-27862 2 Bosch DU mount nut Bosch part number EB11.200.03C
I 26-27479 1 M8x7 Flip Chip Apply grease to outside surface
J 34-20201 1 36.4 Seat Collar
K 26-28150 1 M4x26 Bosch Screw
L 72-25240 1 Bosch TT System Controller Bosch part number EB13.100.000
M 26-27857 1 Bosch TT adapter Bosch part number EB13.200.0AE
Exploded Diagram of Vala
Carbon - Linkage Hardware
label part_number quantity torque name blurb
A 26-15532 2 0.5 Nm M5x5 Set Screw Apply Loctite 242 to threads, titghten until flush
B 26-20124 4 M5x16 Water Bottle screw Apply grease to threads
C 08-22343 1 20 Nm Pivot Axle M15x91 Apply Loctite 242 to threads only, apply grease to shaft only
D 26-15633 2 M6 Tapered Washer Apply grease to surface
E 26-11817 2 M6 Washer
F 26-15947 2 9 Nm M6x20 SHCS Apply Loctite 242 to threads
G 26-27480 1 M8x7 Flip Chip Apply grease to outside surface
H 26-20091 1 15.6 Nm M8x45 Lowhead SHCS Apply Loctite 242 to threads
I 26-27867 1 Bosch charge socket holder Bosch part number EB12.120.01A
J 26-27869 2 Bosch MCx14 Screw Bosch part number F04N.002.663
K 26-27868 1 Bosch COB O-ring Bosch part number EB12.120.019
L 72-25237 1 Bosch charge socket Bosch part number EB12.120.048
M 26-27866 1 Bosch charger port cover Bosch part number EB12.120.01B
N 26-29334 2 Bosch DU mount insert sleeve Bosch part number EB11.200.0GK
O 26-27864 1 30 Nm Bosch DU mount bolt front Bosch part number EB11.200.12M
P 26-27865 1 30 Nm Bosch DU mount bolt rear Bosch part number EB11.200.12H
Q 08-16292 1 20 Nm Pivot axle M15x80.5 Apply Loctite 242 to threads only, apply grease to shaft only
R 26-18382 2 0.65 Nm M4x12 BHCS Apply grease to treads
S 30-27475 1 Fender
T 26-27481 2 16 Nm M10x10 trunnion screw Apply Loctite 242 to threads only, apply grease to shaft only
U 11-12681 2 6900-2RS Bearing
V 26-15533 2 M10x3 Washer Apply grease to inner surface
W 26-27484 2 16 Nm M10x20 bolt Apply Loctite 242 to threads
X 11-12218 2 6902-2RS Max Bearing
Y 26-27483 2 Washer Apply grease to inner surface
Z 26-27482 2 M10x2.6 Flip Chip Apply grease to outside surface
AA 26-25329 1 Cable loop FT NDS
BB 26-15939 1 0.1 Nm M3x12 BHCS Apply Loctite 242 to threads
Heckler 10C Exp View
Carbon - Rear Triangle Hardware, Chainguide, and Chainstay Protector
label part_number quantity name blurb torque
A 08-22209 1 Rear axle 12x173.7 Apply grease to shaft and threads
B 23-23491 1 SCB UDH Interchangeable with Sram UDH
C 26-23492 1 SCB UDH screw Reverse thread 20 Nm
D 26-27487 M10x26 Bolt Apply Loctite 242 to threads only, apply grease to shaft only 16 Nm
E 26-27488 2 Dust Shield Apply grease to inner surface
F 11-27485 6802-2RS Bearing
G 26-27489 2 Bearing spacer Apply grease to shaft
H 26-27486 2 M10x6 Nut Apply grease to inner surface
I 30-27476 Chanistay protector
J 26-15939 M3x12 BHCS Apply Loctite 242 to threads 0.1 Nm
K 26-22938 M4x10 FHCS Apply Loctite 242 to threads 0.65 Nm
L 19-22609 OneUp chainguide
M 26-27839 OneUp chainguide back plate
N 30-27838 Cable Loop Guide
O 26-22358 M3x6 Apply Loctite 242 to threads 0.6 Nm
P 26-22570 M5x12 HHS Apply Loctite 242 to threads 2 Nm
Q 30-21453 Seatstay Protector
Exploded Diagram of Vala
Carbon - Battery
label part_number quantity name torque blurb
A 26-27493 1 Battery mount rear PT600
B 26-28053 4 M4x10 SHCS 1.2 Nm Apply Loctite 242 to threads
C 26-27870 1 Bosch H-Connector
D 78-25241 1 Bosch battery PT600 Bosch part number EB12.100.04X (US/CA), EB12.100.04V (EU, OZ)
E 26-27494 1 Battery mount front PT600
F 26-27912 1 Battery mount rear PT600
Heckler 10C Exp View
Aluminum - Motor, Shuttle Guard, and Remote
label quantity part_number name blurb torque
A 4 26-27915 M5x10 BHCS Apply Loctite 242 to threads 9 Nm
B 1 30-27825 Shuttle guard Line up with battery screws
C 1 72-25239 Bosch DU Performance CX Bosch part number EB11.100.00E
D 1 30-28663 DU Protector
E 4 26-23102 M4x16 BHCS Apply grease to threads 0.65 Nm
F 2 26-21224 M6x10 BHCS Apply loctite 242 to threads 3 Nm
G 2 26-27862 Bosch DU mount nut Bosch part number EB11.200.03C
H 2 26-20124 M5x16 Water Bottle screw Apply grease to threads
I 1 34-20201 36.4 Seat Collar
J 1 72-25240 Bosch TT System Controller Bosch part number EB13.100.000
K 1 26-18382 M4x12 BHCS Apply grease to treads 0.65 Nm
Technical diagram of a Vala AL bicycle frame with labeled parts on a white background
Aluminum - Motor Mounting Hardware
label quantity part_number name blurb torque
A 2 26-21360 Water Bottle Screw
B 2 26-18382 M4x12 BHCS Apply grease to treads 0.65 Nm
C 2 26-15532 M5x5 Set Screw Apply Loctite 242 to threads, titghten until flush 0.5 Nm
D 1 30-28124 PowerMore wire clip Use with Bosch range extender
E 1 26-20091 M8x45 Lowhead SHCS Apply Loctite 242 to threads 22 Nm
F 1 26-27867 Bosch charge socket holder Bosch part number EB12.120.01A
G 1 26-27868 Bosch COB O-ring Bosch part number EB12.120.019
H 1 72-25237 Bosch charge socket Bosch part number EB12.120.048
I 2 26-27869 Bosch MCx14 Screw Bosch part number F04N.002.663
J 1 26-27866 Bosch charger port cover Bosch part number EB12.120.01B
K 1 26-29606 Bosch DU screw wide V2 Bosch part number EB11.200.15J 30 Nm
L 1 26-29605 Bosch insert socket long V2 Bosch part number EB11.200.15H
M 1 26-25329 Cable loop FT NDS
N 1 26-23284 M3x8 BHCS Apply Loctite 242 to threads 0.5 Nm
O 1 26-29607 Bosch insert socket short V2 Bosch part number EB11.200.12F
P 1 26-29608 Bosch DU screw V2 Bosch part number EB11.200.12G 30 Nm
Q 1 30-27475 Fender
R 2 26-18382 M4x12 BHCS Apply grease to treads 0.65 Nm
Technical diagram of a Vala AL bicycle frame with labeled parts on a white background
Aluminum - Linkage Hardware
label quantity part_number name blurb torque
A 1 08-22343 Pivot Axle M15x91 Apply Loctite 242 to threads only, apply grease to shaft only 20 Nm
B 1 26-15633 M6 Tapered Washer Apply grease to surface
C 1 26-11817 M6 Washer
D 1 26-15947 M6x20 SHCS Apply Loctite 242 to threads 9 Nm
E 2 26-15533 M10x3 Washer Apply grease to inner surface
F 2 11-12681 6900-2RS Bearing
G 2 26-27481 M10x10 trunnion screw Apply Loctite 242 to threads only, apply grease to shaft only 16 Nm
H 2 26-28683 SSE Reducer Apply grease to inner surface
I 2 11-12218 6902-2RS Max Bearing
J 2 26-27484 M10x20 bolt Apply Loctite 242 to threads 16 Nm
Technical diagram of a Vala AL bicycle frame with labeled parts on a white background
Aluminum - Rear Triangle Hardware
label quantity part_number name blurb torque
A 1 08-22209 Rear axle 12x173.7 Apply grease to shaft and threads
B 1 23-23491 SCB UDH Interchangeable with Sram UDH
C 1 26-23492 SCB UDH screw Reverse thread 20 Nm
D 2 26-27487 M10x26 Bolt Apply Loctite 242 to threads only, apply grease to shaft only 16 Nm
E 4 26-27488 Dust Shield Apply grease to inner surface
F 4 11-27485 6802-2RS Bearing
G 2 26-27489 Bearing spacer Apply grease to shaft
H 1 30-28664 Chainstay Protector
I 1 26-23284 M3x8 BHCS Apply Loctite 242 to threads 0.5 Nm
J 1 30-27838 Cable Loop Guide
K 1 26-27839 OneUp chainguide back plate
L 2 26-22938 M4x10 FHCS Apply Loctite 242 to threads 0.65 Nm
M 1 19-22609 OneUp chainguide
N 1 26-22570 M5x12 HHS Apply Loctite 242 to threads 2 Nm
O 2 26-22358 M3x6 Apply Loctite 242 to threads 0.6 Nm
P 1 30-21453 Seatstay Protector
Q 1 26-19207 Hose Grommet
Technical diagram of a Vala AL bicycle frame with labeled parts on a white background
Aluminum - Front Triangle Hardware
label quantity part_number name blurb torque
A 4 11-12218 6902-2RS Max Bearing
B 4 26-11612 Bearing Dust Shield Apply grease to inner surface
C 1 26-17707 15x48 Bearing spacer
D 1 08-22343 Pivot Axle M15x91 Apply Loctite 242 to threads only, apply grease to shaft only 20 Nm
E 1 26-17013 15x40.25 Bearing Spacer
F 1 08-16292 Pivot axle M15x80.5 Apply Loctite 242 to threads only, apply grease to shaft only 20 Nm
G 2 26-15633 M6 Tapered Washer Apply grease to surface
H 2 26-11817 M6 Washer
I 2 26-15947 M6x20 SHCS Apply Loctite 242 to threads 9 Nm
Technical diagram of a Vala AL bicycle frame with labeled parts on a white background
Aluminum - Battery
label quantity part_number name blurb torque
A 8 26-28053 M4x10 SHCS Apply Loctite 242 to threads 1.2 Nm
B 1 26-27494 Battery mount front PT600
C 1 78-25241 Bosch battery PT600 Bosch part number EB12.100.04X (US/CA), EB12.100.04V (EU, OZ)
D 1 30-28682 Cable Tray
E 1 26-27870 Bosch H-Connector
F 1 26-27912 Battery mount rear PT600
G 1 26-28681 Battery Mount Rear PT600 Type 2
Technical diagram of a Vala AL eMTB Battery

Dateien

Wenn Du mehr Informationen zu Deinem Bike suchst, findest Du sie im Santa Cruz Bicycles-Benutzerhandbuch.
