Tallboy 5 MY25

There's a "flip chip" on the link where the shock mounts. Just remove the lower shock bolt and flip the chips to the setting you desire.

You should definitely try both, but we typically recommend starting in High. In the High setting, the bike rides a little higher in its travel and supplies the rider with more mid-stroke support. In the Low position, the shock rate becomes more progressive, particularly at the end of the stroke, and there’s some bottom-out resistance to be gained.

Our geometry is based off of a 130mm fork with a 44mm offset. We wouldn't recommend less travel than that, as the steering will be too twitchy and the BB will get a bit low. 140mm is the max travel fork we recommend.

The Tallboy.5 will fit up to a 220mm rotor. The frame is 180mm-direct, so that's the minimum size that's compatible.

Yes, this bike is equipped with ISCG-05 tabs for easy chain guide mounting. Most guides/bash guards that follow the ISCG-05 standard should fit.

This bike uses integrated headset cups. The upper up is 41mm and the lower cup is 52mm. The SHIS name is IS 41/28.6 IS 52/40.For Chris King this is a DropSet.3

The frame is UDH-compatible, but comes with our own machined aluminum hanger. You can replace it with another Santa Cruz hanger or a SRAM UDH.

The Tallboy uses a a 190x45mm shock with 8x30 hardware front and rear.

The Tallboy comes with two bags - a tube purse and a tool wallet. You should be able to fit a superlight tube, a small pump, tire lever, and misc odds and ends in these two bags.

CC frames use the very best carbon materials available. C Carbon frames have all the same features but the trade off for a little less $ is a little more weight. Both versions are made in our own factory, are just as strong and stiff as one another. And both feature our lifetime warranty.

We recommend a 2.5" max on the rear.
