new

Bullit Podium

$13,249.00 USD

Carbon CC Frame
FOX Podium Factory Fork
FOX Float X2 Factory Shock
SRAM X0 Eagle AXS T-Type Drivetrain
Bosch Performance CX BDU38 Drive Unit

Color: Black Pink Splatter

Size: M

Questions? Let’s chat

Get access to the exclusive SCB Owners Club which gives you access to added levels of rider support, treats, opportunities and benefits. Join the club today for free! It takes just five minutes to receive a lifetime of membership perks.

Learn More

We build Santa Cruz bicycles to be durable and long lasting, and then back them up with legendary support and a warranty of the highest standard.

Santa Cruz Bicycles offers free replacement pivot bearings to the original owner for as long as they own their bike.

Material CC

Front (MM) 170

Rear (MM) 170

Wheel Size MX

49.23 22.33

Weight (lbs) 49.23

Weight (kg) 22.33

If you feel the pull of gravity riding but want an extra push to get to the top, the Bullit is for you. The Bosch Performance Line CX motor gets you to the drop-in of the deepest, wildest trails. Built tough for the biggest terrain, the Bullit is the closest it gets to owning both a downhill bike and a chairlift.

Dig Deep

Specs, sizing and support for the Bullit Podium

	M	L	XL
Reach	460	480	500
Stack	631	640	654
Head tube angle	63.6°	63.6°	63.6°
Head Tube Length	110	120	135
Rear Center	443	446	449
Front Center	809	834	860
BB Height	346	346	346
BB Drop Front	27	27	27
BB Drop Rear	9	9	9
Wheelbase	1252	1280	1309
Top Tube Length	596	617	640
Seat Tube Length	400	420	460
Seat Tube Angle	78.7°	78.7°	78.7°

	M	L	XL
Reach	457	477	497
Stack	635	643	656
Head tube angle	63.3°	63.3°	63.3°
Head Tube Length	110	120	135
Rear Center	444	447	450
Front Center	809	834	860
BB Height	342	342	342
BB Drop Front	31	31	31
BB Drop Rear	13	13	13
Wheelbase	1253	1280	1310
Top Tube Length	597	618	641
Seat Tube Length	400	420	460
Seat Tube Angle	78.4°	78.4°	78.4°

Rider Weight (lbs)	Rider Weight (kgs)	Pressure (psi)	Rebound (L/H from closed)	Compression (L/H from closed)
100	45	50	14/8	2/2
120	54	61	13/7	2/2
140	64	73	11/6	2/2
160	73	84	8/5	2/2
180	82	96	6/4	2/2
200	91	108	4/3	2/2
220	100	119	2/1	2/2
240	109	128	1/0	2/2

Rider Weight (lbs)	Rider Weight (kgs)	Pressure (psi)	Sag	Rebound (L/H from closed)	Compression (L/H from closed)
100	45	130	28-30%,	14/6	6/3
120	54	150	28-30%,	13/5	6/3
140	64	170	28-30%,	13/4	6/3
160	73	190	28-30%,	12/3	6/3
180	82	210	28-30%,	11/3	6/3
200	91	230	28-30%,	11/2	6/3
220	100	250	28-30%,	9/2	6/3
240	109	270	28-30%,	7/1	6/3

label	name	quantity	part_number	blurb	torque
A	Head Tube Badge	1	20-27756	Clean frame surface, center on headtube
B	M5x10 BHCS	4	26-27915	Apply Loctite 242 to threads	9 Nm
C	Shuttle guard	1	30-27825	Line up with battery screws
D	Bosch DU Performance CX	1	72-25239	Bosch part number EB11.100.00E
E	M4x16 BHCS	3	26-23102	Apply grease to threads	0.65 Nm
F	DU Protector	1	30-27495
G	M6x10 BHCS	2	26-21224	Apply loctite 242 to threads	3 Nm
H	Bosch DU mount nut	2	26-27862	Bosch part number EB11.200.03C
I	M8x7 Flip Chip	1	26-27480	Apply grease to outside surface
J	36.4 Seat Collar	1	34-20201
K	M4x26 Bosch Screw	1	26-28150
L	Bosch TT System Controller	1	72-25240	Bosch part number EB13.100.000
M	Bosch TT adapter	1	26-27857	Bosch part number EB13.200.0AE

Cart

Bullit Podium Build Kit & Specs

Bullit Podium Sizing & Geometry

Bullit Podium Setup & Support

Bullit Podium

Dig Deep

Build kit
& Specs

Geometry
& Sizing

Setup
& Support

Compare Bikes

Compare Bikes

label	name	quantity	torque	part_number	blurb
A	M5x5 Set Screw	2	0.5 Nm	26-15532	Apply Loctite 242 to threads, titghten until flush
B	Water Bottle Screw	2		26-21360
C	Pivot Axle M15x91	1	20 Nm	08-22343	Apply Loctite 242 to threads only, apply grease to shaft only
D	M6 Tapered Washer	2		26-15633	Apply grease to surface
E	M6 Washer	2		26-11817
F	M6x20 SHCS	2	9 Nm	26-15947	Apply Loctite 242 to threads
G	M8x7 Flip Chip	1		26-27480	Apply grease to outside surface
H	M8x45 Lowhead SHCS	1	15.6 Nm	26-20091	Apply Loctite 242 to threads
I	Bosch charge socket holder	1		26-27867	Bosch part number EB12.120.01A
J	Bosch MCx14 Screw	2		26-27869	Bosch part number F04N.002.663
K	Bosch COB O-ring	1		26-27868	Bosch part number EB12.120.019
L	Bosch charge socket	1		72-25237	Bosch part number EB12.120.048
M	Bosch charger port cover	1		26-27866	Bosch part number EB12.120.01B
N	Bosch DU Insert Sleeve	1		26-29334	Bosch part number EB11.200.0GK
O	Bosch DU mount bolt front	1	30 Nm	26-27864	Bosch part number EB11.200.12M
P	Bosch DU mount bolt rear	1	30 Nm	26-27865	Bosch part number EB11.200.12H
Q	Pivot axle M15x80.5	1	20 Nm	08-16292	Apply Loctite 242 to threads only, apply grease to shaft only
R	M4x8 BHCS	2	0.65 Nm	26-21249	Apply grease to threads
S	Fender	1		30-27475
T	M10x10 trunnion screw	2	16 Nm	26-27481	Apply Loctite 242 to threads only, apply grease to shaft only
U	6900-2RS Bearing	2		11-12681
V	M10x3 Washer	2		26-15533	Apply grease to inner surface
W	M10x20 bolt	2	16 Nm	26-27484	Apply Loctite 242 to threads
X	6902-2RS Max Bearing	2		11-12218
Y	Washer	2		26-27483	Apply grease to inner surface
Z	M10x2.6 Flip Chip	2		26-27482	Apply grease to outside surface

label	name	quantity	part_number	blurb	torque
A	Rear axle 12x173.7	1	08-22209	Apply grease to shaft and threads
B	SCB UDH	1	23-23491	Interchangeable with Sram UDH
C	SCB UDH screw	1	26-23492	Reverse thread	20 Nm
D	M10x26 Bolt	2	26-27487	Apply Loctite 242 to threads only, apply grease to shaft only	16 Nm
E	Dust Shield	4	26-27488	Apply grease to inner surface
F	6802-2RS Bearing	4	11-27485
G	Bearing spacer	2	26-27489	Apply grease to shaft
H	M10x6 Nut	2	26-27486	Apply grease to inner surface
I	Chanistay protector	1	30-27476
J	M3x12 BHCS	1	26-15939	Apply Loctite 242 to threads	0.1 Nm
K	M4x10 FHCS	2	26-22938	Apply Loctite 242 to threads	0.65 Nm
L	OneUp chainguide	1	19-22609
M	OneUp chainguide back plate	1	26-27839
N	Cable Loop Guide	1	30-27838
O	M3x6	2	26-22358	Apply Loctite 242 to threads	0.6 Nm
P	M5x12 HHS	1	26-22570	Apply Loctite 242 to threads	2 Nm
Q	Seatstay Protector	1	30-21453

label	name	quantity	part_number	torque	blurb
A	Battery mount rear PT600	1	26-27493
B	M4x10 SHCS	8	26-28053	1.2 Nm	Apply Loctite 242 to threads
C	Bosch H-Connector	1	26-27870
D	Bosch battery PT600	1	78-25241		Bosch part number EB12.100.04X (US/CA), EB12.100.04V (EU, OZ)
E	Battery mount front PT600	1	26-27494

label	name	quantity	part_number	blurb
A	Bearing Dust Shield	4	26-11612	Apply grease to inner surface
B	6902-2RS Max Bearing	4	11-12218
C	15x48 Bearing spacer	1	26-17707
D	15x40.25 Bearing Spacer	1	26-17013
E	Cable loop FT NDS	1	26-25329
F	M3x12 BHCS	1	26-15939	Apply Loctite 242 to threads

Frame Size	Flip Chip	Setup Key	Setup Cog	32T	34T	36T
M	High	B	7	118	118	118
L	High	A	7	118	118	120
XL	High	A	7	118	120	120
M	Low	A	7	118	118	120
L	Low	A	7	118	120	120
XL	Low	A	7	118	120	120
