Bronson

Front Travel (MM) 160

Rear travel (MM) 150

Wheel Size MX

Santa Cruz Bicycles Bronson Frame Details

ALL-ROUNDER WITH AN ATTITUDE

When you can only have one bike, and your mission is to ride it into oblivion, this is the one. From manicured bike parks to blown-out loamy berms, alpine lines to backyard trails, the Bronson feels just as at home in the air as it does in the dirt. For the rider with a Peter Pan disposition or anyone looking to get into a pan-flat tabletop position, the Bronson encourages bad behavior.

See The Bikes

ANOTHER LAP THE SYNDICATE'S LAURIE AND OLLIE ARE KEEN FOR ANOTHER ONE

STYLE AT SPEED

A WILD SIDE FOR SIDE HITS

The Bronson’s suspension and geometry work in harmony to create a settled, assured ride that feels as if it's whispering to you, ‘You’ve got this. Don’t brake. Go for the side hit. Do it.’ You might even find yourself asking your riding buddies for another lap.

Person on a mountain bike performing a jump in a forest setting

MILLIMETERS MATTER

PULL UP, SEND DEEP

This is the best VPP™ we’ve ever made. There’s more traction on offer, and it makes for very composed descending. The lower VPP™ link is placed low and forward to optimize anti-squat. The result is a plush, open feel with a lot of traction, and minimal kickback on square-edge hits.

Filtri:

MY25 Bronson CC X0 AXS RSV Kalimotxo E10b4f8d 4b84 A2cb 5e59330dbdf2

MY25 Bronson CC X0 AXS RSV TranslucentRootBeer 8c96f908 7caf 4d0a B733 2bf20eca1509

Bronson X0 AXS RSV

Carbon CC

Everything, plus legendary carbon Reserve wheels.

$9,349

Confronta

MY25 Bronson CC X0 AXS TranslucentRootBeer 37142a41 C35a 4b8a A5a9 Be33cafecfc2

MY25 Bronson CC X0 AXS Kalimotxo 77e72ec3 D72f 402a Bbd7 456ca0a8ba78

Bronson X0 AXS

Carbon CC

For the factory Jackson. The lightest CC carbon frame, full SRAM X0 electronic Transmission, Fox 36 Factory suspension and SRAM Maven brakes

$8,299

Confronta

Bronson GX AXS

Carbon C

The high-performance all-rounder. Full SRAM GX Eagle electronic Transmission, SRAM Maven brakes, and Fox Elite suspension

$7,249

new

Confronta

MY26 Bronson C GlossCarbon 26915ef1 F57c 44b7 9ec8 De188e520517

MY26 Bronson C MattePoblanoGreen B77b3385 Af65 49ab B0ff 9e3b833c3090

Bronson 90

Carbon C

Core score upgrade. Upgraded hubs, headset, and dropper post. Upgraded suspension with more adjustment, SRAM 90 cable-operated T-Type Transmission and SRAM Maven brakes.

$6,099

Confronta

MY26 Bronson C MattePoblanoGreen 000bf8f2 4fb3 8f6e 4a008cbdf352

MY26 Bronson C GlossCarbon 37316aa6 905e 47f7 A3be Dad5a0198020

Bronson 70

Carbon C

Base model with same tires and big rotors as all Bronsons. SRAM 70 cable actuated T-Type Transmission.

$5,149

Confronta

MY25 Bronson C S TranslucentRootBeer Dd926e03 Ba3e 45ba Af8e A708e73514b2

MY25 Bronson C S Kalimotxo 5f550d07 Ea56 4ca9 A256 3e09f7253d6a

Bronson S

Carbon C

The workhorse. Upgraded hubs, headset, and dropper post. Upgraded suspension with more adjustment, SRAM Eagle cable-operated drivetrain and four-piston SRAM brakes.

$5,899

Confronta

MY25 Bronson C R Kalimotxo 4e6cdac2 F7f1 B236 B33227483e89

MY25 Bronson C R TranslucentRootBeer A7f6a2e3 C1e9 4df7 C1f1434030a1

Bronson R

Carbon C

Base model with same tires and big rotors as all Bronsons. Quality RockShox Lyrik fork and Fox Float Rhythm rear shock suspension, just without all the external tuning dials.

$4,999

Confronta

MY25 Bronson CC FactoryFLoatX Frame TranslucentRootBeer B5815f4a 98e7 4a0a A0b8 Afa9b52ff04b

MY25 Bronson CC FactoryFLoatX Frame Kalimotxo 733c854b F9cc 413b B92ff37ef33b

Bronson Frame CC

Carbon CC

$4,049

Confronta

Deals On Bronsons

Current Offers

Sorry, there are no products that match.

Design Details

VPP™

The dual link VPP™ suspension design offers a balance of pedaling efficiency and all-out bump-chomping prowess.

Scopri di più

Carbon Mastery

Choose between our top-end, lightweight Carbon CC frame or the value-minded Carbon C frame. Both come with a lifetime warranty.

Scopri di più

Design details of Design Details Built2Last HT BR NO MT TB HKSL HK BL HB

Built to Last

Bikes aren't throwaway items, but they get thrown around. From the tough frames to free bearings for life, Santa Cruz bikes are built to last.

Scopri di più

Glovebox

Keep your ride essentials close to hand inside the Glovebox. Also comes with a tailored Tool Wallet and Tube Purse.

Scopri di più

Sweat the details

	s	m	l	xl	xxl
Reach (Hi/Lo)	435/432	460/457	480/478	500/498	525/523
Stack (Hi/Lo)	623/625	632/634	641/643	659/661	668/670
Head Tube Angle (Hi/Lo)	64.2°/63.9°	64.2°/63.9°	64.2°/63.9°	64.2°/63.9°	64.2°/63.9°
Head Tube Length (Hi/Lo)	110	120	130	150	160
Rear Center (Hi/Lo)	437	439	442	445	448
Front Center (Hi/Lo)	771	800	825	853	883
BB Height (Hi/Lo)	344/341	344/341	344/341	344/341	344/341
BB Drop Front (Hi/Lo)	29/32	29/32	29/32	29/32	29/32
BB Drop Rear (Hi/Lo)	10/13	10/13	10/13	10/13	10/13
Wheelbase (Hi/Lo)	1208	1240	1267	1299	1331
Top Tube Length (Hi/Lo)	572	595	614	636	662
Seat Tube Length (Hi/Lo)	380	405	430	460	500
Seat Tube Angle (Hi/Lo)	77.6°/77.3°	77.9°/77.6°	78.2°/77.9°	78.3°/78°	78.4°/78.1°
Standover Height (Hi/Lo)	721	723	725	727	731

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Sag	Rebound (da chiuso)
100	45	135	30%, 17-17.5mm	9
120	54	155	30%, 17-17.5mm	8
140	64	175	30%, 17-17.5mm	8
160	73	190	30%, 17-17.5mm	7
180	82	210	30%, 17-17.5mm	7
200	91	230	30%, 17-17.5mm	6
220	100	250	30%, 17-17.5mm	6
240	109	265	30%, 17-17.5mm	5
260	118	285	30%, 17-17.5mm	5

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Rebound (da chiuso)
100	45	40	14
120	54	50	13
140	64	60	12
160	73	70	11
180	82	80	11
200	91	90	10
220	100	100	9
240	109	110	8

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Sag	Rebound (da chiuso)
100	45	125	30%, 17-17.5mm	8
120	54	145	30%, 17-17.5mm	7
140	64	165	30%, 17-17.5mm	7
160	73	180	30%, 17-17.5mm	6
180	82	200	30%, 17-17.5mm	5
200	91	220	30%, 17-17.5mm	4
220	100	240	30%, 17-17.5mm	4
240	109	255	30%, 17-17.5mm	3
260	118	275	30%, 17-17.5mm	3

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Rebound (da chiuso)
120	54	66	13
140	64	74	11
160	73	82	9
180	82	89	7
200	91	99	5
220	100	109	3
240	109	117	1

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Sag	Rebound (da chiuso)	Compressione
100	45	125	30%, 17-17.5mm	8	3-5
120	54	145	30%, 17-17.5mm	7	3-5
140	64	165	30%, 17-17.5mm	7	3-5
160	73	180	30%, 17-17.5mm	6	3-5
180	82	200	30%, 17-17.5mm	5	3-5
200	91	220	30%, 17-17.5mm	4	3-5
220	100	240	30%, 17-17.5mm	4	3-5
240	109	255	30%, 17-17.5mm	3	3-5
260	118	275	30%, 17-17.5mm	3	3-5

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Rebound (L/H da chiuso)	Compressione (L/H dal chiuso)
120	54	70	9,8	10,5
130	59	74	8,7	10,5
140	64	78	7,6	10,5
150	68	82	7,6	10,5
160	73	86	6,5	10,5
170	77	89	6,5	10,5
180	82	94	5,4	10,5
190	86	99	4,3	10,5
200	91	105	4,3	10,5
210	95	109	3,2	10,5
220	100	113	2,1	10,5
230	104	117	2,1	10,5
240	109	121	1,0	10,5

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Sag	Rebound (da chiuso)	Compressione
100	45	125	30%, 17-17.5mm	8	3-5
120	54	145	30%, 17-17.5mm	7	3-5
140	64	165	30%, 17-17.5mm	7	3-5
160	73	180	30%, 17-17.5mm	6	3-5
180	82	200	30%, 17-17.5mm	5	3-5
200	91	220	30%, 17-17.5mm	4	3-5
220	100	240	30%, 17-17.5mm	4	3-5
240	109	255	30%, 17-17.5mm	3	3-5
260	118	275	30%, 17-17.5mm	3	3-5

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Sag	Rebound (L/H da chiuso)	Compressione (L/H dal chiuso)
120	54	66	10/5	9/8	10/5
140	64	74	10/5	7/7	10/5
160	73	82	10/5	7/6	10/5
180	82	89	10/5	6/4	10/5
200	91	99	10/5	4/3	10/5
220	100	109	10/5	3/1	10/5
240	109	117	10/5	1/0	10/5

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Sag	Rebound (da chiuso)	Compressione
100	45	125	30%, 17-17.5mm	8	3-5
120	54	145	30%, 17-17.5mm	7	3-5
140	64	165	30%, 17-17.5mm	7	3-5
160	73	180	30%, 17-17.5mm	6	3-5
180	82	200	30%, 17-17.5mm	5	3-5
200	91	220	30%, 17-17.5mm	4	3-5
220	100	240	30%, 17-17.5mm	4	3-5
240	109	255	30%, 17-17.5mm	3	3-5
260	118	275	30%, 17-17.5mm	3	3-5

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Rebound (L/H da chiuso)	Compressione (L/H dal chiuso)
120	54	70	9,8	10,5
130	59	74	8,7	10,5
140	64	78	7,6	10,5
150	68	82	7,6	10,5
160	73	86	6,5	10,5
170	77	89	6,5	10,5
180	82	94	5,4	10,5
190	86	99	4,3	10,5
200	91	105	4,3	10,5
210	95	109	3,2	10,5
220	100	113	2,1	10,5
230	104	117	2,1	10,5
240	109	121	1,0	10,5

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Sag	Rebound (da chiuso)
100	45	125	30%, 17-17.5mm	8
120	54	145	30%, 17-17.5mm	7
140	64	165	30%, 17-17.5mm	7
160	73	180	30%, 17-17.5mm	6
180	82	200	30%, 17-17.5mm	5
200	91	220	30%, 17-17.5mm	4
220	100	240	30%, 17-17.5mm	4
240	109	255	30%, 17-17.5mm	3
260	118	275	30%, 17-17.5mm	3

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Rebound (da chiuso)
120	54	70	13
130	59	74	12
140	64	78	11
150	68	82	10
160	73	86	9
170	77	89	8
180	82	94	7
190	86	99	6
200	91	105	5
210	95	109	4
220	100	113	3
230	104	117	2
240	109	121	1

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Sag	Rebound (da chiuso)	Compressione
100	45	125	30%, 17-17.5mm	8	3-5
120	54	145	30%, 17-17.5mm	7	3-5
140	64	165	30%, 17-17.5mm	7	3-5
160	73	180	30%, 17-17.5mm	6	3-5
180	82	200	30%, 17-17.5mm	5	3-5
200	91	220	30%, 17-17.5mm	4	3-5
220	100	240	30%, 17-17.5mm	4	3-5
240	109	255	30%, 17-17.5mm	3	3-5
260	118	275	30%, 17-17.5mm	3	3-5

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Rebound (L/H da chiuso)	Compressione (L/H dal chiuso)
120	54	70	9,8	10,5
130	59	74	8,7	10,5
140	64	78	7,6	10,5
150	68	82	7,6	10,5
160	73	86	6,5	10,5
170	77	89	6,5	10,5
180	82	94	5,4	10,5
190	86	99	4,3	10,5
200	91	105	4,3	10,5
210	95	109	3,2	10,5
220	100	113	2,1	10,5
230	104	117	2,1	10,5
240	109	121	1,0	10,5

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Sag	Rebound (da chiuso)	Compressione
100	45	125	30%, 17-17.5mm	8	3-5
120	54	145	30%, 17-17.5mm	7	3-5
140	64	165	30%, 17-17.5mm	7	3-5
160	73	180	30%, 17-17.5mm	6	3-5
180	82	200	30%, 17-17.5mm	5	3-5
200	91	220	30%, 17-17.5mm	4	3-5
220	100	240	30%, 17-17.5mm	4	3-5
240	109	255	30%, 17-17.5mm	3	3-5
260	118	275	30%, 17-17.5mm	3	3-5

Peso del Rider (lbs)	Peso del Rider (kg)	Pressione (psi)	Rebound (L/H da chiuso)	Compressione (L/H dal chiuso)
120	54	70	9,8	10,5
130	59	74	8,7	10,5
140	64	78	7,6	10,5
150	68	82	7,6	10,5
160	73	86	6,5	10,5
170	77	89	6,5	10,5
180	82	94	5,4	10,5
190	86	99	4,3	10,5
200	91	105	4,3	10,5
210	95	109	3,2	10,5
220	100	113	2,1	10,5
230	104	117	2,1	10,5
240	109	121	1,0	10,5

label	part_number	quantity	name	blurb
A	29-27474	1	Upper Link
B	11-12681	2	6900-2RS Bearing
C	26-15533	2	M10x3 Washer	Apply grease to inner surface
D	26-11612	2	Bearing Dust Shield	Apply grease to inner surface
E	11-12218	2	6902-2RS Max Bearing

label	part_number	quantity	name	blurb	torque
A	29-27473	1	Lower Link
B	11-17708	4	6902-1ZR Bearing
C	26-11612	4	Bearing Dust Shield	Apply grease to inner surface
D	26-19126	1	15x28 Bearing spacer
E	26-17013	1	15x40.25 Bearing Spacer
F	26-12678	1	M6 Grease Fitting		9 Nm
G	26-15532	1	M5x5 Set Screw	Apply Loctite 242 to threads, titghten until flush	0.5 Nm

label	part_number	quantity	name	torque	blurb
A	26-22843	1	Glovebox lid
B	26-25333	1	Glovebox bezel
C	26-23284	4	M3x8 BHCS	0.5 Nm	Apply Loctite 242 to threads
D	30-23225	2	Glovebox nut

label	part_number	quantity	name	blurb	torque
A	08-22209	1	Rear axle 12x173.7	Apply grease to shaft and threads
B	23-23491	1	SCB UDH	Interchangeable with Sram UDH
C	26-23492	1	SCB UDH screw	Reverse thread	20 Nm
D	30-27472	1	Chainstay Protector
E	26-15939	1	M3x12 BHCS	Apply Loctite 242 to threads	0.1 Nm
F	30-21453	1	Seatstay Protector
G	30-23094	1	Lower Link Fender
H	26-18382	2	M4x12 BHCS	Apply grease to treads	0.65 Nm

label	part_number	quantity	torque	name	blurb
A	26-20122	2	16 Nm	M10x23 Screw	Apply Loctite 242 to threads only, apply grease to shaft only
B	08-22343	1	20 Nm	Pivot Axle M15x91	Apply Loctite 242 to threads only, apply grease to shaft only
C	26-15633	3		M6 Tapered Washer	Apply grease to surface
D	26-11817	3		M6 Washer
E	26-15947	3	9 Nm	M6x20 SHCS	Apply Loctite 242 to threads
F	08-16291	1	20 Nm	Pivot axle M15x68.5	Apply Loctite 242 to threads only, apply grease to shaft only
G	08-16292	1	20 Nm	Pivot axle M15x80.5	Apply Loctite 242 to threads only, apply grease to shaft only
H	26-15946	1	5.6 Nm	M5x20 SHCS	Apply Loctite 242 to threads
I	26-12652	1		M5 Washer
J	26-27530	1		M5 Tapered Washer	Apply grease to surface
K	08-27508	1	13.6Nm	Shock Mount Axle M10x63	Apply Loctite 242 to threads only, apply grease to shaft only
L	26-22461	1	20 Nm	M8x45 Shock Bolt	Apply Loctite 242 to threads
M	26-21452	1		M8x2 Flip Chip NDS	Apply grease to surface
N	26-21451	1		M8x2 Flip Chip DS	Apply grease to surface

label	part_number	quantity	name	blurb	torque
A	20-27756	1	Head Tube Badge	Clean frame surface, center on headtube
B	30-23750	1	Shuttle Guard Mount
C	30-22560	1	Shuttle Guard
D	26-21249	2	M4x8 BHCS	Apply grease to threads	0.65 Nm
E	30-27471	1	Downtube Protector
F	26-18382	2	M4x12 BHCS	Apply grease to treads	0.65 Nm
G	34-20201	1	36.4 Seat Collar

Frame Size	Flip Chip	Setup Key	Setup Cog	30T	32T	34T
S	High	B	7	116	116	118
M	High	B	7	116	116	118
L	High	B	7	116	118	118
XL	High	B	7	116	118	118
XXL	High	B	7	118	118	120
S	Low	B	7	116	116	118
M	Low	B	7	116	116	118
L	Low	B	7	116	118	118
XL	Low	B	7	116	118	118
XXL	Low	B	7	118	118	120

Dig Deep

Sizing and support for the Bronson.

Design details of MY26 Bronson Details Dbae802e 2c6e A314 7766bb00be67

Geometry
& Sizing

Setup
& Support

“Santa Cruz has hit the nail on the head with the redesign of the Bronson”

“Santa Cruz has possibly created the best feeling VPP bike I’ve ridden, aside from the bump-eating V10.”

“I simply could not fault a day out in the hills on the new Bronson. The changes aren’t all that apparent to the eye–you’d have to know the VPP has been moved–but the real world changes are massive and they make this bike a joy to ride.”

Design details of MY25 Bronson Details Cdab9e20 Ed96 Aee5 1c29e3309280

THE RUNDOWN

SO WHAT'S THE BRONSON ALL ABOUT?

CAN'T BE BOTHERED TO READ OR STILL LOOKING FOR ANSWERS ON THE BRONSON? WATCH AND LEARN.

Also Consider...

THE DEFINITIVE MOUNTAIN BIKE

See the Hightower

Ab7b3647 466d 8dd3 E667c104dcda SCB Heckler SL2023

FAST, LIGHT, OR POWERFUL–CHOOSE ALL THREE

See the Heckler SL

Cart

Bronson

ALL-ROUNDER WITH AN ATTITUDE

A WILD SIDE FOR SIDE HITS

PULL UP, SEND DEEP

Bronson X0 AXS RSV

Bronson X0 AXS

Bronson GX AXS

Bronson 90

Bronson 70

Bronson S

Bronson R
